Description

  • Engine Model
    24 (V)
  • Rated Power
    750 (Ah)
  • Load Capacity
    1,500 (kg)
  • Reference Model
    15BTR-9

※ The specifications above are subject to change without prior notice for quality improvement.
※ The colors in this catalog may be different from actual colors.

ModelBattery Voltage
V
Battery Capacity
Ah
Load Capacity
kg
Load Center
mm
Max. Lifting Height(STD)
mm
Min. Turning Radius
mm
Travel Speed (Unloaded)
km/h
10BTR-9246251,0005003,0251,33513
13BTR-9247501,2505003,0251,42513
15BTR-9247501,5005003,0251,48013
